Rosemount-K-0085 Pipe Clamp Sensor and 3144S Transmitter

Rosemount™ 0085 파이프 클램프 센서 및 3144S 온도 트랜스미터

사양

Rosemount™ 0085 파이프 클램프 온도 센서
파이프 클램프 재질
ASTM 316 SST(1.4401), ASTM 304 SST(1.4301), 듀플렉스 F51(1.4462), 탄소강(1.0037)
도선
PTFE 절연, 은 도금 구리 와이어
절연 저항
500VDC 및 실온에서 측정 시 1000MΩ의 최소 절연 저항
교정 옵션
-50~300°C(-58~572°F)에서 Class A 센서
인증/승인
위험 지역, 전체 인증 목록은 전체 사양 참조
Rosemount™ 3144S Temperature Transmitter
Input
Dual and single sensor capability with universal sensor inputs (RTD, T/C, mV, ohms)
Output Signal
4-20 mA/HART® protocol
Housing
Dual-compartment field mount
Display/Interface
Large Graphical Backlit LCD display with Quick Service Buttons, multiple lines and percent range graph
Accuracy
± 0.05 °C reference accuracy
Stability
± 0.25 °C for 20 years (Ultra Performance), or 10 years (Classic Performance)
Diagnostics
Basic diagnostics, Loop Integrity, RTD Measurement Protection, Hot Backup™ capability, Sensor Drift Alert, Thermocouple Degradation, Configurable Process Alerts
Calibration Options
Transmitter-Sensor Matching (Callendar-Van Dusen constants)
Certifications/Approvals
SIL2 certified and SIL3 capable to IEC 61508 by an independent 3rd party, hazardous location, marine type, see Quick Start Guide for complete list of certifications

특징

Rosemount™ 0085 파이프 클램프 온도 센서
  • 센서는 어플리케이션 요구를 충족하도록 -58~572°F(-50~300°C)의 광범위한 온도 지원
  • 정확한 프로세스 온도 측정을 위해 Rosemount X-well™ 기술을 채택한 Rosemount 648 무선 제품에 직접 마운팅
  • 광범위한 클램프 스타일과 사이즈 및 재질을 이용해 어디에나 설치가 가능하며 애플리케이션 유연성 제공
  • 파이프의 절단 또는 용접이 필요하지 않은 손쉬운 설치
  • 응답 시간을 개선하기 위해 은 팁으로 설계된 플래티넘 RTD 온도 센서
  • 내구성 및 안정성을 위해 고속, 중액이나 미립자를 가진 어플리케이션을 견딤
  • 안전성을 강화하기 위한 비방해적 설계를 통해 독성 유체가 프로세스에 침투하지 않음
  • 성능을 향상하기 위한 스프링 장착 센서는 최고의 표면 접촉 보장
Rosemount™ 3144S Temperature Transmitter
  • Industry-leading accuracy and reliability for best performance in critical control and safety applications
  • 20-year long-term stability extends calibration intervals to reduce trips to the field
  • 20-year limited warranty provides assurance and peace of mind that comes with purchasing a Rosemount product
  • ReadyConnect™ Technology provides plug-and-play sensor configuration to help you save time and eliminate errors
  • Rosemount X-well Technology measures temperatures up to 650°C (1202°F) without a process penetration for reduced design, installation and maintenance costs
  • RTD Measurement Protection converts your configuration from a 4-wire to a 3-wire configuration if a wire is broken or damaged, helping to avoid loss of measurement and downtime
  • Bluetooth® Connectivity helps you work easier, safer, and more efficiently with simplified operator rounds, a consistent application experience across Emerson devices, and by avoiding the need for a hot work permit
  • Loop Integrity diagnostic continuously monitors the health of the entire electrical loop to detect potential failures before they happen
  • Hot Backup™ capability and Sensor Drift Alert utilizing dual sensors ensure measurement integrity
  • Thermocouple Degradation diagnostic monitors thermocouple health to detect degradation before failure
  • Guided Proof Testing provides an easy, step-by-step process to help ensure you are operating safely and properly
  • Dual-compartment housing provides superior protection in harsh environments
